• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 6x SATA 6Gb/s connectors
• 2x M.2 slots (M-Key)
• 1x USB 3.2 Gen 1 5Gbps Type-C port
• 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
• 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 1x 4-pin CPU fan connector
• 1x 4-pin water-pump fan connector
• 6x 4-pin system fan connectors
• 1x Front panel audio connector
• 2x System panel connectors
• 1x Chassis Intrusion connector
• 1x 4-pin RGB LED connector
• 2x 3-pin RAINBOW LED connectors
• 1xTPM module connector
• 1x Clear CMOS jumper

Съхранение:

• 6x SATA 6Gb/s ports
• 2x M.2 slots (Key M)
  • M2_2 slot (from AMD B550 chipset)
• • M2_1 slot (from AMD Processor)

Памет:

• 4x DDR4 memory slots, support up to 128GB
• Поддържа DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
• Поддържа DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733 / 3866/ 4000/ 4133/ 4266/ 4400+ MHz by A-XMP OC режим
  • 1DPC 1R max speed 4400 MHz
  • 1DPC 2R max speed 3866 MHz
  • 2DPC 1R max speed 4000 MHz
  • 2DPC 2R max speed 3600 MHz
• Двуканална архитектура на паметта
• Поддържа ECC UDIMM memory (non-ECCрежим)
• Поддържа non-ECC UDIMM memory
• Поддържа небуферирана памет
